IC-M94DE VHF Marine Transducer with DSC & AIS
IC-M94DE VHF Marine Transducer with DSC & AIS
IC-M94DE VHF Marine Transducer with DSC & AIS
IC-M94DE VHF Marine Transducer with DSC & AIS
IC-M94DE VHF Marine Transducer with DSC & AIS
IC-M94DE VHF Marine Transducer with DSC & AIS

IC-M94DE VHF Marine Transducer with DSC & AIS

No reviews yet
Part Number:

VHF Marine Transceiver with DSC & AIS Receiver

AIS Traffic Info, Now in Your Hand

  • AIS Receiver and DSC in One Marine Handheld
  • 5 W RF Output Power and 10 Hours of Operating Time
  • Class-Leading 1500 mW Audio Output
  • Simplified Navigation Function
  • Float’n Flash and MOB Auto Set Functions
  • Integrated GPS receiver　
  • Active noise cancelling technology
  • IPX7 waterproof (1 m depth of water for 30 minutes)
  • Dualwatch and Tri-watch functions
  • Favourite channel function
  • Supports 4-digit channels
  • AquaQuake™ prevents audio degradation from a water-logged speaker
SPECIFICATIONS
GENERAL
Frequency range TX
156.025 - 157.425 MHz

RX
156.300 – 162.000 MHz

DSC
156.525 MHz

AIS (RX)
162.025 MHz
Usable channels INT, USA, WX channels
Type of emission 16K0G3E (FM), 16K0G2B (DSC),
16K0G2B (AIS)
Current drain TX (5 W/ 1 W output)
1400 mA/700 mA (appox.)

RX (Inter SP/Exter SP Max. Audio)
700 mA/350 mA (approx.)
Operating temperature range –10°C to +55°C
Antenna impedance 50 Ω
Dimensions
(W x H x D)
(projections not included)		 60.9 x 145.8 x 43.8 mm
Weight (approximate) 357 g
(With BP-306, antenna, MB-133)
TRANSMITTER
Output power
(Hi/Low)		 5 W / 1 W
Max. frequency deviation ±5 kHz
Frequency stability ±10 ppm
Spurious emissions 0.25 μW typical
RECEIVER
Sensitivity at 20 dB SINAD
–6 dBμ emf typical

DSC receiver (at 1% BER)
–3 dBμ emf typical

AIS receiver (at 20% PER)
-107 dBm
Squelch sensitivity (Threshold) –6 dBμ emf typical
Adjacent channel selectivity 65 dB

DSC receiver (at 1% BER)
73 dBμ
Spurious response 65 dB

DSC receiver (at 1% BER)
73 dBμ
Inter-modulation 65 dB

DSC receiver (at 1% BER)
68 dBμ
Hum and Noise 40dB
Audio Output Power (at 10% distortion) Internal SP
1500 mW typical (8 Ω load)

External SP
350 mW typical (8 Ω load)
